Heavy Type Welded Wire Mesh

Heavy Type Welded Wire Mesh

Heavy Type Welded Wire Mesh is also called heavy duty welded wire mesh. It is different from other kind of welded wire mesh for its super big wire diameter, or big opening size, or big width. It is welded by special heavy duty welding machinery.

Application: Due to its specialty, it has the capacity of supporting very heavy stuffs, so heavy-duty welded wire mesh is extensively used in industry and agriculture building, transportation, mining, stone baskets, runway enclosures, draining rack, fence etc.

Assortments available:

  • Heavy Type/Duty Stainless Steel Welded Wire Mesh
  • Heavy Type/Duty Hot Dip Galvanized Welded Wire Mesh Panel
  • Heavy Type/Duty Electric Galvanized Welded Wire Mesh Panel
  • Heavy Type/Duty PVC Coated Welded Wire Mesh Panel

Material Quality: We choose the best low carbon wire or stainless steel wire material available in China, we also have very strict quality requirement for PVC powder( for 2.0-2.5mm) to ensure it is the leading quality within China.

Automatic Welding Machine & Well-Trained Staff: Our advanced digital controlled heavy type machineries and well-trained workers ensure the quality of strong welding joints, and even mesh size.

Heavy Type Welded Wire Mesh Heavy Type Welded Wire Mesh

Heavy Type Welded Wire MeshHeavy Type Welded Wire MeshHeavy Type Welded Wire MeshHeavy Type Welded Wire Mesh

Specifications

Roll Width: 24inch, 36inch, 1Metre, 48inch, 72inch or 84inch.

Roll Length: 100feet or 150feet.

Note: other roll width or roll length can be made according to request.

Mesh Size Wire Diameter Wire Diameter
In MM In Inch MM BWG
25.4mm 1Inch 2.0mm - 3.0mm BWG14 - 11
25.4 x 50.8mm 1 x 2inch 2.0mm - 4.0mm BWG14 - 8
50.8mm 2 Inch 2.0mm - 4.0mm BWG14 - 8
50.8 x76.2mm 2 x 3Inch 2.0mm - 5.0mm BWG14 - 6
76.2mm 3Inch 2.0mm - 5.0mm BWG14 - 6
50.8 x 101.8mm 2 x 4Inch 2.0mm - 6.0mm BWG14 - 4
101.6mm 4Inch 2.0mm - 6.0mm BWG14 - 4
127mm 5Inch 2.0mm - 6.0mm BWG14 - 4
152.4mm 6Inch 2.0mm - 6.0mm BWG14 - 4

For Heavy Type Welded Wire Mesh, Heavy Duty Welded Wire Mesh,mesh size bigger than 6inch or other mesh size besides above, please send us your inquiry, as our digital controlled machine can set up any mesh size even it is not a standard type.
